Vacuum-pickup 6-AXIS BACK-TO-BACK SCREW LOCKING MACHINE

Main functions

  • The screw material can be obtained by vacuum suction or magnetic suction;
  • Support deep hole, inclined hole, gourd surface, and surfaces of different heights;
  • Support the simultaneous installation of two types of screws (one product), and the intelligent servo electric screwdriver can set three types of the same torque at the same time;
  • The sheet metal frame has strong rigidity, and the height position of the feeder can be adjusted, supporting products with different heights and strong compatibility;
  • Closed loop stepper motor, high precision, position compensation, no step loss, small vibration amplitude,
  • Equipped with high-performance motion control system, easy to programwith foolproof programming;
  • Paired with the Weilun Tong human-machine interface touch screen, the lock status is dynamically displayed, and the electri
  • 技术参数
  • 设备用途
锁附范围 Locking range 200*200*90mm (单边 unilaterallY*Z)
外形尺寸 Overall dimensions 760*930*780mm(宽长高)(Width, Length, Height)
驱动方式 Drive Type 闭环精密步进电机;Closed loop precision stepper motor
定位精度 positioning accuracy ±0.02 mm
控制系统 control system 触摸屏 + 高性能运动控制卡 Touch screen+high-performance motion control card
电批系统 Electric batch system 智能伺服电批,任意设定扭力与转速 Intelligent servo electric batch, freely set torque and speed
锁付效率 Lock payment efficiency 约 about 1.5s
程序容量 program capacity 100 组 group
设备功率 Equipment power 1200W
电源 power supply 220VAC
气源 gas source 5-6KPa
整机总量 Total weight 150Kg

Suitable for mobile phones, cordless phones, calculators, navigators, speakers, cameras, learning devices, small appliances, toys, etc.
